Fast-Controller Data Acquisition Platform
MODEL TYPES
FC-DAQ
FC-DAQ+
FC-DAQ
Second Order Effects’ FC-DAQ Base model offers a cost-optimized, high-performance solution for customers requiring a scalable platform for high-speed instrumentation interfacing and real-time control. FC-DAQ series digitizers replace dissimilar instrument and sensor interfaces for improved system-level scalability and data quality by standardizing hardware and software. FC-DAQ can be configured with custom firmware and DSP to interface to a wide range of analog and digital signals.
Product details
64 QTY high speed differential analog inputs (± 0.35% FSR @ 8 MS/s)
64 QTY high accuracy differential analog inputs (± 0.02% FSR @ 776 S/s)
32 QTY differential analog outputs (40 kHz update rate)
46 QTY isolated digital I/O channels (> 1 kV isolation)
AMD Zynq UltraScale+ MPSoC with customizable DSP
VHDCI instrument input / output connectors
10 GbE streaming output
2U, 19 inch rack-mountable
MODEL TYPES
FC-DAQ
FC-DAQ+
FC-DAQ
Second Order Effects’s FC-DAQ can be configured with custom firmware and DSP to interface to a wide range of analog and digital signals. Custom hardware configurations available – configuration can be customized to meet user needs. Indicate custom configuration needed on the order form to prompt a configuration call for scoping and pricing.
Product details
64 QTY high speed differential analog inputs (± 0.35% FSR @ 8 MS/s)
64 QTY high accuracy differential analog inputs (± 0.02% FSR @ 776 S/s)
32 QTY differential analog outputs (40 kHz update rate)
46 QTY isolated digital I/O channels (> 1 kV isolation)
AMD Zynq UltraScale+ MPSoC with customizable DSP
VHDCI instrument input / output connectors
10 GbE streaming output
2U, 19 inch rack-mountable
MODEL TYPES
FC-DAQ
FC-DAQ+
FC-DAQ
Second Order Effects’ FC-DAQ Base model offers a cost-optimized, high-performance solution for customers requiring a scalable platform for high-speed instrumentation interfacing and real-time control. FC-DAQ series digitizers replace dissimilar instrument and sensor interfaces for improved system-level scalability and data quality by standardizing hardware and software. FC-DAQ can be configured with custom firmware and DSP to interface to a wide range of analog and digital signals.
Product details
64 QTY high speed differential analog inputs (± 0.35% FSR @ 8 MS/s)
64 QTY high accuracy differential analog inputs (± 0.02% FSR @ 776 S/s)
32 QTY differential analog outputs (40 kHz update rate)
46 QTY isolated digital I/O channels (> 1 kV isolation)
AMD Zynq UltraScale+ MPSoC with customizable DSP
VHDCI instrument input / output connectors
10 GbE streaming output
2U, 19 inch rack-mountable
Interested in FC-DAQ?
Submit your information below and our team will contact you with availability, technical specifications, and next steps.
