Thermal Control Electronics
TCE
Second Order Effects’ Thermal Control Electronics (TCE) provides a reliable, configurable solution for precision thermal management in demanding environments.
Designed with a channelized architecture, each channel integrates an independent heater driver, temperature sensor interface, and externally configurable setpoint to enable localized, closed-loop thermal control. The system automatically actuates heater outputs when measured temperatures fall below the defined setpoint and disables them once a configurable hysteresis threshold is exceeded, ensuring stable and efficient temperature regulation.
Product details
4 heater channels
No onboard software
Rated output power per channel: 20 W
Redundant, wide-range logic power inputs: 24-38 V
Hardware configurable temperature setpoint per channel
Direct connection from power pin to heater
Individual power inputs for each heater channel
Design de-rated to NASA EEE-INST-002*
Qualified to MIL-STD 461, SMC-S-016*
